2008 KAWASAKI TERYX 750 4x4

AT A GLANCE:
750cc V-twin mid-ship mounted engine
7.5 inches front travel and 7.25 inches rear travel with gas-charged rear shocks with reservoirs
26-inch Maxxis tires
Sealed rear wet brake system
500-pound capacity cargo bed and 1300 pound towing capacity

ENGINE:
— 90-degree 749cc V-twin engine is positioned mid-ship for optimum front/rear balance
— Straight intake tracts and 34mm downdraft carburetors enhance power delivery throughout the rpm range
— Intake ducts located by the cargo bed direct cooling air to the engine
— Aluminum cylinders are Electrofusion-plated for light weight, long wear and excellent heat dispersion
— Engine can be started in any gear when the rear brake is applied
— Electronically controlled Kawasaki Engine Brake Control helps to slow the RSV when traversing steep down hills

TRANSMISSION & 4 WHEEL DRIVE SYSTEM:
— CVT features high and low ranges, plus reverse
— Rider can select two- or four-wheel-drive operation by pressing a button located on the dash
— Limited-slip front differential reduces steering effort under normal four-wheel drive operation, while Variable Front Differential Control permits rider to distribute torque equally to left and right front wheels for maximum traction via a hand lever
— Rear wheels are locked and always turning together for cornering control

CHASSIS:
— Large-diameter thin-walled tubular steel frame
— 11.2 inches of ground clearance
— Long dual front A-arm suspension and narrow frame concept provides 7.5 inches of travel and features adjustable gas-charged Kayaba shocks
— Independent rear suspension has adjustable gas-charged Kayaba shocks with reservoirs that provides 7.25 inches of travel

BRAKES:
— Dual front 200mm disc brakes with two-piston 27mm calipers and Kawasaki’s sealed, oil-bathed, multi-disc rear brake system
— Front discs are recessed in wheels for protection from debris

TIRES & WHEELS:
— 26-inch Maxxis tires specially built for the Teryx 750 4x4

BODYWORK & ERGONOMICS:
— Bucket seats with retractable three-point seat belts
— Foot guards designed into the floor and body
— Padded steering wheel positioned low for better control
— Body work is made of high-gloss scratch resistant Thermo-Plastic Olefin
— Steel floor boards and engine guards for maximum protection
— Dual 40W headlights and dual taillights
— Cargo bed has 500 lb capacity, tie down hooks in all four corners and cargo net standard

TERYX 750 4x4 LE ADDITIONAL FEATURES:
- Digital Meter
- Dual retractable cup holders
- Hard top
- Half-Windshield
- Tilting cargo bed with gas assist

2008 KAWASAKI TERYX 750 4x4 SPECIFICATIONS:

Engine: Liquid-cooled, 90-degree, four-stroke V-twin
Valve system: SOHC, four valves per cylinder
Displacement: 749cc
Starting system: Electric
Bore x stroke: 85 x 66mm
Compression ratio: 8.8:1
Carburetion: (2) Keihin CVKR-34
Ignition: Digital DC-CDI
Transmission: Continuously variable belt-drive transmission with high and low range, plus reverse, and Kawasaki Engine Brake Control
Final drive: Selectable four-wheel drive with Variable Front Differential Control, shaft
Frame: Large diameter, thin-walled, high-tensile tubular steel
Front suspension / wheel travel: Adjustable dual A-arm with gas charged shocks / 7.5 in.
Rear suspension / wheel travel: Adjustable Independent Rear Suspension (IRS) with gas charged, reservoir shocks / 7.3 in.
Front tires: Maxxis 26x8-12
Rear tires: Maxxis 26x10-12
Front brakes: Dual hydraulic discs with 2-piston calipers
Rear brake: Sealed, oil-bathed, multi-disc
Overall length: 115.7 in.
Overall width: 58.3 in.
Overall height: 75.4 in.
Wheelbase: 75.8 in.
Ground clearance: 11.2 in.
Lighting: (2) 40W headlights, (2) TK W taillight, TKW stoplight
Cargo bed capacity: 500 lbs, 44.1 W x 32.7 L x 12 in. H
Towing capacity: 1300 lbs
Dry weight: TBD
Fuel capacity: 8.0 gal.
Instruments: R/N/P/4WD indicators, water temp and oil pressure lamps, digital meter (LE only)
Standard Colors: Sunbeam Red, Woodsman Green, REALTREE™ Hardwoods Green® HD
MSRP standard / LE: TBD
